Agilent Assaymap bravo adapter – Evotip Holder

This is a 3D printing file (.stl) that contains the Evotip Holder for the AssayMap Bravo position 7

Agilent AssayMap Bravo Adapter – Equilibration Holder

This is a 3D printing file (.stl) that contains the Equilibration Holder for the Assaymap Bravo position 8

Opentrons ot-2 Evotip Loading protocol

Here you find the Opentrons OT-2 Evotip loading protocol generator that allows you to generate a protocol that suits your needs. The protocol uses the Opentrons 8-channel P300 and P20 pipettes for loading of 8 Evotip Pure at a time and up to 288 Evotip Pure per protocol run.

Generate protocol file and import to Opentrons app.

Agilent AssayMap Bravo – Single Column Protocol (AssayMap Head)

Here you find the Single Column protocol that was designed to support user flexibility and allows for transfer of 8 samples (or a single column from a 96 well plate) at a time using the AssayMap head.

Agilent AssayMap Bravo – Full Head Protocol (AssayMap Head)

Here you find the Full Head protocol that was designed to transfer a full set of samples from individual positions in a 96 well plate to the Evotips using the AssayMap head.

Agilent AssayMap Bravo – Single column protocol (LT Head)

Here you find the Single Column protocol that was designed to support user flexibility and allows for transfer of 8 samples (or a single column from a 96 well plate) at a time using the LT head.

Agilent AssayMap Bravo – Full Head Protocol (LT Head)

Here you find the Full Head method that was designed to transfer a full set of samples from individual positions in a 96 well plate to the Evotips using the LT head.

Semi-automated AssayMAP Bravo protocol for robust Evotip loading and high-throughput analysis on the Evosep One

App note of semi-automated AssayMAP Bravo protocol for loading of Evotips
